Basic information

Entry
Database: EMDB / ID: EMD-0607
TitleCryo-EM structure of TRPV5 with calmodulin bound
Map datasharpened map with 1 CaM bound
Sample
  • Cell: Complex of TRPV5 with calmodulin bound
    • Protein or peptide: Transient receptor potential cation channel subfamily V member 5
    • Protein or peptide: Calmodulin
  • Ligand: CALCIUM ION
KeywordsTRP channel / MEMBRANE PROTEIN
Function / homology
Function and homology information


regulation of urine volume / positive regulation of ryanodine-sensitive calcium-release channel activity / calcium ion import across plasma membrane / negative regulation of ryanodine-sensitive calcium-release channel activity / calcium ion homeostasis / regulation of release of sequestered calcium ion into cytosol by sarcoplasmic reticulum / calcium ion transmembrane transport / calcium channel activity / spindle pole / calcium ion transport ...regulation of urine volume / positive regulation of ryanodine-sensitive calcium-release channel activity / calcium ion import across plasma membrane / negative regulation of ryanodine-sensitive calcium-release channel activity / calcium ion homeostasis / regulation of release of sequestered calcium ion into cytosol by sarcoplasmic reticulum / calcium ion transmembrane transport / calcium channel activity / spindle pole / calcium ion transport / protein homotetramerization / calmodulin binding / apical plasma membrane / protein domain specific binding / calcium ion binding / protein-containing complex / identical protein binding / metal ion binding / plasma membrane / cytosol / cytoplasm
Similarity search - Function
Transient receptor potential cation channel subfamily V member 5 / Transient receptor potential cation channel subfamily V member 5/6 / Transient receptor potential cation channel subfamily V / : / Ankyrin repeat / EF-hand domain pair / Ankyrin repeats (3 copies) / Ankyrin repeat profile. / Ankyrin repeat region circular profile. / ankyrin repeats ...Transient receptor potential cation channel subfamily V member 5 / Transient receptor potential cation channel subfamily V member 5/6 / Transient receptor potential cation channel subfamily V / : / Ankyrin repeat / EF-hand domain pair / Ankyrin repeats (3 copies) / Ankyrin repeat profile. / Ankyrin repeat region circular profile. / ankyrin repeats / Ankyrin repeat / EF-hand, calcium binding motif / Ankyrin repeat-containing domain superfamily / EF-Hand 1, calcium-binding site / EF-hand calcium-binding domain. / EF-hand calcium-binding domain profile. / EF-hand domain / Ion transport domain / Ion transport protein / EF-hand domain pair
Similarity search - Domain/homology
Calmodulin / Transient receptor potential cation channel subfamily V member 5
Similarity search - Component
Biological speciesOryctolagus cuniculus (rabbit) / Bos taurus (cattle)
Methodsingle particle reconstruction / cryo EM / Resolution: 3.3 Å
AuthorsDang S / van Goor MK
Funding support United States, Netherlands, European Union, France, 8 items
OrganizationGrant numberCountry
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)R01GM098672 United States
National Institutes of Health/National Center for Research Resources (NIH/NCRR)S10OD020054 United States
National Institutes of Health/National Center for Research Resources (NIH/NCRR)S10OD021741 United States
National Institutes of Health/National Institute of Neurological Disorders and Stroke (NIH/NINDS)R35NS105038 United States
Netherlands Organisation for Scientific Research (NWO)451001004 Netherlands
European Union (EU)748058European Union
Human Frontier Science Program (HFSP) France
Howard Hughes Medical Institute (HHMI) United States
CitationJournal: Proc Natl Acad Sci U S A / Year: 2019
Title: Structural insight into TRPV5 channel function and modulation.
Authors: Shangyu Dang / Mark K van Goor / Daniel Asarnow / YongQiang Wang / David Julius / Yifan Cheng / Jenny van der Wijst /
Abstract: TRPV5 (transient receptor potential vanilloid 5) is a unique calcium-selective TRP channel essential for calcium homeostasis. Unlike other TRPV channels, TRPV5 and its close homolog, TRPV6, do not ...TRPV5 (transient receptor potential vanilloid 5) is a unique calcium-selective TRP channel essential for calcium homeostasis. Unlike other TRPV channels, TRPV5 and its close homolog, TRPV6, do not exhibit thermosensitivity or ligand-dependent activation but are constitutively open at physiological membrane potentials and modulated by calmodulin (CaM) in a calcium-dependent manner. Here we report high-resolution electron cryomicroscopy structures of truncated and full-length TRPV5 in lipid nanodiscs, as well as of a TRPV5 W583A mutant and TRPV5 in complex with CaM. These structures highlight the mechanism of calcium regulation and reveal a flexible stoichiometry of CaM binding to TRPV5.
History
DepositionFeb 22, 2019-
Header (metadata) releaseMar 20, 2019-
Map releaseApr 24, 2019-
UpdateMar 20, 2024-
Current statusMar 20, 2024Processing site: RCSB / Status: Released

-
Structure visualization

Movie
  • Surface view with section colored by density value
  • Surface level: 0.15
  • Imaged by UCSF Chimera
  • Download
  • Surface view colored by cylindrical radius
  • Surface level: 0.15
  • Imaged by UCSF Chimera
  • Download
  • Surface view with fitted model
  • Atomic models: PDB-6o20
  • Surface level: 0.15
  • Imaged by UCSF Chimera
  • Download
Movie viewer
Structure viewerEM map:
SurfViewMolmilJmol/JSmol
Supplemental images


Downloads & links

-
Map

FileDownload / File: emd_0607.map.gz / Format: CCP4 / Size: 64 MB / Type: IMAGE STORED AS FLOATING POINT NUMBER (4 BYTES)
Annotationsharpened map with 1 CaM bound
Projections & slices

Image control

Size
Brightness
Contrast
Others
AxesZ (Sec.)Y (Row.)X (Col.)
1.06 Å/pix.
x 256 pix.
= 271.104 Å		1.06 Å/pix.
x 256 pix.
= 271.104 Å		1.06 Å/pix.
x 256 pix.
= 271.104 Å

Surface

Projections

Slices (1/3)

Slices (1/2)

Slices (2/3)

Images are generated by Spider.

Voxel sizeX=Y=Z: 1.059 Å
Density

Histogram

Histogram (log scale)
Contour LevelBy AUTHOR: 0.15 / Movie #1: 0.15
Minimum - Maximum-0.38624346 - 0.61685777
Average (Standard dev.)0.001679637 (±0.033558242)
SymmetrySpace group: 1
Details

EMDB XML:

Map geometry
Axis orderXYZ
Origin000
Dimensions256256256
Spacing256256256
CellA=B=C: 271.104 Å
α=β=γ: 90.0 °

CCP4 map header:

modeImage stored as Reals
Å/pix. X/Y/Z1.0591.0591.059
M x/y/z256256256
origin x/y/z0.0000.0000.000
length x/y/z271.104271.104271.104
α/β/γ90.00090.00090.000
MAP C/R/S123
start NC/NR/NS000
NC/NR/NS256256256
D min/max/mean-0.3860.6170.002

-
Supplemental data

-
Additional map: sharpened map with C4 symmetry applied

Fileemd_0607_additional_1.map
Annotationsharpened map with C4 symmetry applied
Projections & Slices
AxesZYX

Projections

Slices (1/2)
Density Histograms

Histogram

Histogram (log scale)

-
Additional map: sharpened map with C2 symmetry applied

Fileemd_0607_additional_2.map
Annotationsharpened map with C2 symmetry applied
Projections & Slices
AxesZYX

Projections

Slices (1/2)
Density Histograms

Histogram

Histogram (log scale)

-
Additional map: sharpened map without symmetry applied

Fileemd_0607_additional_3.map
Annotationsharpened map without symmetry applied
Projections & Slices
AxesZYX

Projections

Slices (1/2)
Density Histograms

Histogram

Histogram (log scale)

-
Additional map: sharpened map with 2 CaM bound

Fileemd_0607_additional_4.map
Annotationsharpened map with 2 CaM bound
Projections & Slices
AxesZYX

Projections

Slices (1/2)
Density Histograms

Histogram

Histogram (log scale)

-
Sample components

-
Entire : Complex of TRPV5 with calmodulin bound

EntireName: Complex of TRPV5 with calmodulin bound
Components
  • Cell: Complex of TRPV5 with calmodulin bound
    • Protein or peptide: Transient receptor potential cation channel subfamily V member 5
    • Protein or peptide: Calmodulin
  • Ligand: CALCIUM ION

-
Supramolecule #1: Complex of TRPV5 with calmodulin bound

SupramoleculeName: Complex of TRPV5 with calmodulin bound / type: cell / ID: 1 / Parent: 0 / Macromolecule list: #1-#2
Source (natural)Organism: Oryctolagus cuniculus (rabbit)

-
Macromolecule #1: Transient receptor potential cation channel subfamily V member 5

MacromoleculeName: Transient receptor potential cation channel subfamily V member 5
type: protein_or_peptide / ID: 1 / Number of copies: 5 / Enantiomer: LEVO
Source (natural)Organism: Oryctolagus cuniculus (rabbit)
Molecular weightTheoretical: 82.899656 KDa
Recombinant expressionOrganism: Homo sapiens (human)
SequenceString: MGACPPKAKG PWAQLQKLLI SWPVGEQDWE QYRDRVNMLQ QERIRDSPLL QAAKENDLRL LKILLLNQSC DFQQRGAVGE TALHVAALY DNLEAATLLM EAAPELAKEP ALCEPFVGQT ALHIAVMNQN LNLVRALLAR GASVSARATG AAFRRSPHNL I YYGEHPLS ...String:
MGACPPKAKG PWAQLQKLLI SWPVGEQDWE QYRDRVNMLQ QERIRDSPLL QAAKENDLRL LKILLLNQSC DFQQRGAVGE TALHVAALY DNLEAATLLM EAAPELAKEP ALCEPFVGQT ALHIAVMNQN LNLVRALLAR GASVSARATG AAFRRSPHNL I YYGEHPLS FAACVGSEEI VRLLIEHGAD IRAQDSLGNT VLHILILQPN KTFACQMYNL LLSYDEHSDH LQSLELVPNH QG LTPFKLA GVEGNTVMFQ HLMQKRKHVQ WTCGPLTSTL YDLTEIDSWG EELSFLELVV SSKKREARQI LEQTPVKELV SFK WKKYGR PYFCVLASLY ILYMICFTTC CIYRPLKLRD DNRTDPRDIT ILQQKLLQEA YVTHQDNIRL VGELVTVTGA VIIL LLEIP DIFRVGASRY FGQTILGGPF HVIIITYASL VLLTMVMRLT NMNGEVVPLS FALVLGWCSV MYFARGFQML GPFTI MIQK MIFGDLMRFC WLMAVVILGF ASAFHITFQT EDPNNLGEFS DYPTALFSTF ELFLTIIDGP ANYSVDLPFM YCITYA AFA IIATLLMLNL FIAMMGDTHW RVAQERDELW RAQVVATTVM LERKMPRFLW PRSGICGYEY GLGDRWFLRV ENHHDQN PL RVLRYVEAFK CSDKEDGQEQ LSEKRPSTVE SGMLSRASVA FQTPSLSRTT SQSSNSHRGW EILRRNTLGH LNLGLDLG E GDGEEVYHF

UniProtKB: Transient receptor potential cation channel subfamily V member 5

-
Macromolecule #2: Calmodulin

MacromoleculeName: Calmodulin / type: protein_or_peptide / ID: 2 / Number of copies: 1 / Enantiomer: LEVO
Source (natural)Organism: Bos taurus (cattle)
Molecular weightTheoretical: 19.023912 KDa
Recombinant expressionOrganism: Escherichia coli-Pichia pastoris shuttle vector pPpARG4 (others)
SequenceString:
MGSSHHHHHH SSGLVPRGSH MADQLTEEQI AEFKEAFSLF DKDGDGTITT KELGTVMRSL GQNPTEAELQ DMINEVDADG NGTIDFPEF LTMMARKMKD TDSEEEIREA FRVFDKDGNG YISAAELRHV MTNLGEKLTD EEVDEMIREA DIDGDGQVNY E EFVQMMTA K

UniProtKB: Calmodulin

-
Macromolecule #3: CALCIUM ION

MacromoleculeName: CALCIUM ION / type: ligand / ID: 3 / Number of copies: 4 / Formula: CA
Molecular weightTheoretical: 40.078 Da

-
Experimental details

-
Structure determination

Methodcryo EM
Processingsingle particle reconstruction
Aggregation stateparticle

-
Sample preparation

Concentration1 mg/mL
BufferpH: 8
Component:
ConcentrationFormulaName
150.0 mMNaClsodium chloride
2.0 mMTCEPtris(2-carboxyethyl)phosphine
50.0 mMHEPES4-(2-hydroxyethyl)-1-piperazineethanesulfonic acid
5.0 mMCaCl2calcium chloride
0.02 %LMNG2,2-didecylpropane-1,3-bis-beta-D-maltopyranoside
GridModel: Quantifoil R1.2/1.3 / Material: COPPER / Mesh: 400 / Support film - Material: CARBON / Support film - topology: HOLEY / Pretreatment - Type: GLOW DISCHARGE / Pretreatment - Time: 30 sec. / Pretreatment - Atmosphere: AIR / Pretreatment - Pressure: 101.325 kPa
VitrificationCryogen name: ETHANE / Chamber humidity: 100 % / Chamber temperature: 293 K

-
Electron microscopy

MicroscopeFEI TITAN KRIOS
Image recordingFilm or detector model: GATAN K2 SUMMIT (4k x 4k) / Detector mode: SUPER-RESOLUTION / Number grids imaged: 1 / Number real images: 1135 / Average exposure time: 10.0 sec. / Average electron dose: 63.0 e/Å2
Electron beamAcceleration voltage: 300 kV / Electron source: FIELD EMISSION GUN
Electron opticsIllumination mode: FLOOD BEAM / Imaging mode: BRIGHT FIELD
Sample stageSpecimen holder model: FEI TITAN KRIOS AUTOGRID HOLDER / Cooling holder cryogen: NITROGEN
Experimental equipment
Model: Titan Krios / Image courtesy: FEI Company

+
Image processing

Particle selectionNumber selected: 482348 / Details: automated picked
Startup modelType of model: EMDB MAP
EMDB ID:

0593

Final reconstructionApplied symmetry - Point group: C1 (asymmetric) / Resolution.type: BY AUTHOR / Resolution: 3.3 Å / Resolution method: FSC 0.143 CUT-OFF / Software - Name: cisTEM / Number images used: 34604
Initial angle assignmentType: RANDOM ASSIGNMENT / Software - Name: cryoSPARC
Final angle assignmentType: MAXIMUM LIKELIHOOD / Software - Name: cryoSPARC
Final 3D classificationNumber classes: 3 / Software - Name: cisTEM

-
Atomic model buiding 1

Initial modelPDB ID:

6o1n


Chain - Source name: PDB / Chain - Initial model type: experimental model
RefinementProtocol: AB INITIO MODEL
Output model

PDB-6o20:
Cryo-EM structure of TRPV5 with calmodulin bound

+
