- EMDB-27872: Cryo-EM structure of the PAC1R-PACAP27-Gs complex -

+
Open data


ID or keywords:

Loading...

-
Basic information

Entry
Database: EMDB / ID: EMD-27872
TitleCryo-EM structure of the PAC1R-PACAP27-Gs complex
Map dataConsensus map of PAC1R-PACAP27-Gs complex, postprocessed, -25 B factor sharpened
Sample
  • Complex: Gs coupled Pituitary adenylate cyclase-activating polypeptide type I receptor complex with PACAP27 peptide
    • Complex: Guanine nucleotide-binding protein G(s) subunit alpha isoforms short, Guanine nucleotide-binding protein G(I)/G(S)/G(T) subunit beta-1, Guanine nucleotide-binding protein G(I)/G(S)/G(O) subunit gamma-2, Pituitary adenylate cyclase-activating polypeptide type I receptor
      • Protein or peptide: Guanine nucleotide-binding protein G(s) subunit alpha isoforms short
      • Protein or peptide: Guanine nucleotide-binding protein G(I)/G(S)/G(T) subunit beta-1
      • Protein or peptide: Guanine nucleotide-binding protein G(I)/G(S)/G(O) subunit gamma-2
      • Protein or peptide: Pituitary adenylate cyclase-activating polypeptide type I receptor
    • Complex: Nanobody35
      • Protein or peptide: Nanobody35
    • Complex: Pituitary adenylate cyclase activating polypeptide-27
      • Protein or peptide: Pituitary adenylate cyclase-activating polypeptide
  • Ligand: water
Keywordsmembrane protein / drug discovery / G protein coupled receptor / signalling
Function / homology
Function and homology information


negative regulation of response to reactive oxygen species / development of primary female sexual characteristics / pituitary adenylate cyclase activating polypeptide activity / vasoactive intestinal polypeptide receptor activity / positive regulation of growth hormone secretion / positive regulation of chemokine (C-C motif) ligand 5 production / positive regulation of cAMP-mediated signaling / NGF-independant TRKA activation / regulation of G protein-coupled receptor signaling pathway / neuropeptide hormone activity ...negative regulation of response to reactive oxygen species / development of primary female sexual characteristics / pituitary adenylate cyclase activating polypeptide activity / vasoactive intestinal polypeptide receptor activity / positive regulation of growth hormone secretion / positive regulation of chemokine (C-C motif) ligand 5 production / positive regulation of cAMP-mediated signaling / NGF-independant TRKA activation / regulation of G protein-coupled receptor signaling pathway / neuropeptide hormone activity / neuropeptide binding / G protein-coupled peptide receptor activity / positive regulation of small GTPase mediated signal transduction / insulin secretion / peptide hormone receptor binding / positive regulation of inositol phosphate biosynthetic process / positive regulation of calcium ion transport into cytosol / peptide hormone binding / PKA activation in glucagon signalling / hair follicle placode formation / adenylate cyclase binding / negative regulation of cell cycle / mu-type opioid receptor binding / developmental growth / corticotropin-releasing hormone receptor 1 binding / intracellular transport / D1 dopamine receptor binding / bicellular tight junction / positive regulation of protein kinase activity / neuropeptide signaling pathway / Hedgehog 'off' state / multicellular organismal response to stress / beta-2 adrenergic receptor binding / adenylate cyclase-activating adrenergic receptor signaling pathway / activation of adenylate cyclase activity / adenylate cyclase activator activity / cAMP-mediated signaling / positive regulation of GTPase activity / trans-Golgi network membrane / caveola / female pregnancy / ionotropic glutamate receptor binding / insulin-like growth factor receptor binding / G-protein beta/gamma-subunit complex binding / Olfactory Signaling Pathway / bone development / Activation of the phototransduction cascade / adenylate cyclase-modulating G protein-coupled receptor signaling pathway / G beta:gamma signalling through PLC beta / Presynaptic function of Kainate receptors / Thromboxane signalling through TP receptor / G-protein activation / adenylate cyclase-activating G protein-coupled receptor signaling pathway / G protein-coupled acetylcholine receptor signaling pathway / Activation of G protein gated Potassium channels / Inhibition of voltage gated Ca2+ channels via Gbeta/gamma subunits / Prostacyclin signalling through prostacyclin receptor / Glucagon signaling in metabolic regulation / G beta:gamma signalling through CDC42 / cognition / ADP signalling through P2Y purinoceptor 12 / G beta:gamma signalling through BTK / Synthesis, secretion, and inactivation of Glucagon-like Peptide-1 (GLP-1) / Sensory perception of sweet, bitter, and umami (glutamate) taste / small GTPase binding / photoreceptor disc membrane / platelet aggregation / Adrenaline,noradrenaline inhibits insulin secretion / Glucagon-type ligand receptors / Vasopressin regulates renal water homeostasis via Aquaporins / G alpha (z) signalling events / cellular response to catecholamine stimulus / Glucagon-like Peptide-1 (GLP1) regulates insulin secretion / ADORA2B mediated anti-inflammatory cytokines production / sensory perception of taste / ADP signalling through P2Y purinoceptor 1 / adenylate cyclase-activating dopamine receptor signaling pathway / G beta:gamma signalling through PI3Kgamma / cellular response to prostaglandin E stimulus / Cooperation of PDCL (PhLP1) and TRiC/CCT in G-protein beta folding / GPER1 signaling / G-protein beta-subunit binding / regulation of protein localization / Inactivation, recovery and regulation of the phototransduction cascade / neuron projection development / heterotrimeric G-protein complex / G alpha (12/13) signalling events / extracellular vesicle / sensory perception of smell / signaling receptor complex adaptor activity / Thrombin signalling through proteinase activated receptors (PARs) / GTPase binding / cell-cell signaling / response to estradiol / retina development in camera-type eye / phospholipase C-activating G protein-coupled receptor signaling pathway / Ca2+ pathway / signaling receptor activity / positive regulation of cold-induced thermogenesis / G alpha (i) signalling events
Similarity search - Function
GPCR, family 2, pituitary adenylate cyclase activating polypeptide type 1 receptor / : / Glucagon/GIP/secretin/VIP / Peptide hormone / Glucagon / GIP / secretin / VIP family signature. / Glucagon like hormones / G-protein coupled receptors family 2 signature 1. / Hormone receptor domain / GPCR, family 2, extracellular hormone receptor domain / G-protein coupled receptors family 2 profile 1. ...GPCR, family 2, pituitary adenylate cyclase activating polypeptide type 1 receptor / : / Glucagon/GIP/secretin/VIP / Peptide hormone / Glucagon / GIP / secretin / VIP family signature. / Glucagon like hormones / G-protein coupled receptors family 2 signature 1. / Hormone receptor domain / GPCR, family 2, extracellular hormone receptor domain / G-protein coupled receptors family 2 profile 1. / Domain present in hormone receptors / GPCR family 2, extracellular hormone receptor domain superfamily / G-protein coupled receptors family 2 signature 2. / GPCR, family 2, secretin-like, conserved site / GPCR, family 2, secretin-like / 7 transmembrane receptor (Secretin family) / GPCR, family 2-like / G-protein coupled receptors family 2 profile 2. / G-protein alpha subunit, group S / G-alpha domain profile. / Guanine nucleotide binding protein (G-protein), alpha subunit / G protein alpha subunit, helical insertion / G-protein alpha subunit / G protein alpha subunit / G-protein, gamma subunit / G-protein gamma subunit domain profile. / GGL domain / G-protein gamma-like domain superfamily / G-protein gamma-like domain / GGL domain / G protein gamma subunit-like motifs / Guanine nucleotide-binding protein, beta subunit / G-protein, beta subunit / G-protein beta WD-40 repeat / WD40 repeat, conserved site / Trp-Asp (WD) repeats signature. / Trp-Asp (WD) repeats profile. / Trp-Asp (WD) repeats circular profile. / WD domain, G-beta repeat / WD40 repeats / WD40 repeat / WD40-repeat-containing domain superfamily / WD40/YVTN repeat-like-containing domain superfamily / P-loop containing nucleoside triphosphate hydrolase
Similarity search - Domain/homology
Pituitary adenylate cyclase-activating polypeptide / Pituitary adenylate cyclase-activating polypeptide type I receptor / Guanine nucleotide-binding protein G(I)/G(S)/G(O) subunit gamma-2 / Guanine nucleotide-binding protein G(I)/G(S)/G(T) subunit beta-1 / Guanine nucleotide-binding protein G(s) subunit alpha isoforms short
Similarity search - Component
Biological speciesHomo sapiens (human) / Lama glama (llama)
Methodsingle particle reconstruction / cryo EM / Resolution: 2.3 Å
AuthorsPiper SJ / Danev R / Sexton P / Wootten D
Funding support Australia, United Kingdom, Japan, 5 items
OrganizationGrant numberCountry
National Health and Medical Research Council (NHMRC, Australia)1155302 Australia
National Health and Medical Research Council (NHMRC, Australia)1150083 Australia
National Health and Medical Research Council (NHMRC, Australia)1154434 Australia
Royal Society United Kingdom
Japan Science and Technology Japan
CitationJournal: Nat Commun / Year: 2022
Title: Understanding VPAC receptor family peptide binding and selectivity.
Authors: Sarah J Piper / Giuseppe Deganutti / Jessica Lu / Peishen Zhao / Yi-Lynn Liang / Yao Lu / Madeleine M Fletcher / Mohammed Akhter Hossain / Arthur Christopoulos / Christopher A Reynolds / ...Authors: Sarah J Piper / Giuseppe Deganutti / Jessica Lu / Peishen Zhao / Yi-Lynn Liang / Yao Lu / Madeleine M Fletcher / Mohammed Akhter Hossain / Arthur Christopoulos / Christopher A Reynolds / Radostin Danev / Patrick M Sexton / Denise Wootten /
Abstract: The vasoactive intestinal peptide (VIP) and pituitary adenylate cyclase-activating polypeptide (PACAP) receptors are key regulators of neurological processes. Despite recent structural data, a ...The vasoactive intestinal peptide (VIP) and pituitary adenylate cyclase-activating polypeptide (PACAP) receptors are key regulators of neurological processes. Despite recent structural data, a comprehensive understanding of peptide binding and selectivity among different subfamily receptors is lacking. Here, we determine structures of active, Gs-coupled, VIP-VPAC1R, PACAP27-VPAC1R, and PACAP27-PAC1R complexes. Cryo-EM structural analyses and molecular dynamics simulations (MDSs) reveal fewer stable interactions between VPAC1R and VIP than for PACAP27, more extensive dynamics of VIP interaction with extracellular loop 3, and receptor-dependent differences in interactions of conserved N-terminal peptide residues with the receptor core. MD of VIP modelled into PAC1R predicts more transient VIP-PAC1R interactions in the receptor core, compared to VIP-VPAC1R, which may underlie the selectivity of VIP for VPAC1R over PAC1R. Collectively, our work improves molecular understanding of peptide engagement with the PAC1R and VPAC1R that may benefit the development of novel selective agonists.
History
DepositionAug 17, 2022-
Header (metadata) releaseNov 23, 2022-
Map releaseNov 23, 2022-
UpdateMay 1, 2024-
Current statusMay 1, 2024Processing site: RCSB / Status: Released

-
Structure visualization

Supplemental images


Downloads & links

-
Map

FileDownload / File: emd_27872.map.gz / Format: CCP4 / Size: 91.1 MB / Type: IMAGE STORED AS FLOATING POINT NUMBER (4 BYTES)
AnnotationConsensus map of PAC1R-PACAP27-Gs complex, postprocessed, -25 B factor sharpened
Voxel sizeX=Y=Z: 0.83 Å
Density
Contour LevelBy AUTHOR: 0.009
Minimum - Maximum-0.025407564 - 0.070032634
Average (Standard dev.)-0.00006411625 (±0.001974956)
SymmetrySpace group: 1
Details

EMDB XML:

Map geometry
Axis orderXYZ
Origin000
Dimensions288288288
Spacing288288288
CellA=B=C: 239.04 Å
α=β=γ: 90.0 °

-
Supplemental data

-
Mask #1

Fileemd_27872_msk_1.map
Projections & Slices
AxesZYX

Projections

Slices (1/2)
Density Histograms

Histogram

Histogram (log scale)

-
Additional map: Consensus map of PAC1R-PACAP27-Gs complex, refinement map

Fileemd_27872_additional_1.map
AnnotationConsensus map of PAC1R-PACAP27-Gs complex, refinement map
Projections & Slices
AxesZYX

Projections

Slices (1/2)
Density Histograms

Histogram

Histogram (log scale)

-
Additional map: Consensus map of PAC1R-PACAP27-Gs complex, postprocessed, -25 B...

Fileemd_27872_additional_2.map
AnnotationConsensus map of PAC1R-PACAP27-Gs complex, postprocessed, -25 B factor sharpened
Projections & Slices
AxesZYX

Projections

Slices (1/2)
Density Histograms

Histogram

Histogram (log scale)

-
Additional map: Receptor focused map of PAC1R-PACAP27-Gs complex

Fileemd_27872_additional_3.map
AnnotationReceptor focused map of PAC1R-PACAP27-Gs complex
Projections & Slices
AxesZYX

Projections

Slices (1/2)
Density Histograms

Histogram

Histogram (log scale)

-
Additional map: CryoSPARC non-uniform refinement map of PAC1R-PACAP27-Gs complex

Fileemd_27872_additional_4.map
AnnotationCryoSPARC non-uniform refinement map of PAC1R-PACAP27-Gs complex
Projections & Slices
AxesZYX

Projections

Slices (1/2)
Density Histograms

Histogram

Histogram (log scale)

-
Half map: Half map 1 of Consensus refinement of PAC1R-PACAP27-Gs complex

Fileemd_27872_half_map_1.map
AnnotationHalf map 1 of Consensus refinement of PAC1R-PACAP27-Gs complex
Projections & Slices
AxesZYX

Projections

Slices (1/2)
Density Histograms

Histogram

Histogram (log scale)

-
Half map: Half map 2 of Consensus refinement of PAC1R-PACAP27-Gs complex

Fileemd_27872_half_map_2.map
AnnotationHalf map 2 of Consensus refinement of PAC1R-PACAP27-Gs complex
Projections & Slices
AxesZYX

Projections

Slices (1/2)
Density Histograms

Histogram

Histogram (log scale)

-
Sample components

+
Entire : Gs coupled Pituitary adenylate cyclase-activating polypeptide typ...

EntireName: Gs coupled Pituitary adenylate cyclase-activating polypeptide type I receptor complex with PACAP27 peptide
Components
  • Complex: Gs coupled Pituitary adenylate cyclase-activating polypeptide type I receptor complex with PACAP27 peptide
    • Complex: Guanine nucleotide-binding protein G(s) subunit alpha isoforms short, Guanine nucleotide-binding protein G(I)/G(S)/G(T) subunit beta-1, Guanine nucleotide-binding protein G(I)/G(S)/G(O) subunit gamma-2, Pituitary adenylate cyclase-activating polypeptide type I receptor
      • Protein or peptide: Guanine nucleotide-binding protein G(s) subunit alpha isoforms short
      • Protein or peptide: Guanine nucleotide-binding protein G(I)/G(S)/G(T) subunit beta-1
      • Protein or peptide: Guanine nucleotide-binding protein G(I)/G(S)/G(O) subunit gamma-2
      • Protein or peptide: Pituitary adenylate cyclase-activating polypeptide type I receptor
    • Complex: Nanobody35
      • Protein or peptide: Nanobody35
    • Complex: Pituitary adenylate cyclase activating polypeptide-27
      • Protein or peptide: Pituitary adenylate cyclase-activating polypeptide
  • Ligand: water

+
Supramolecule #1: Gs coupled Pituitary adenylate cyclase-activating polypeptide typ...

SupramoleculeName: Gs coupled Pituitary adenylate cyclase-activating polypeptide type I receptor complex with PACAP27 peptide
type: complex / ID: 1 / Parent: 0 / Macromolecule list: #1-#6

+
Supramolecule #2: Guanine nucleotide-binding protein G(s) subunit alpha isoforms sh...

SupramoleculeName: Guanine nucleotide-binding protein G(s) subunit alpha isoforms short, Guanine nucleotide-binding protein G(I)/G(S)/G(T) subunit beta-1, Guanine nucleotide-binding protein G(I)/G(S)/G(O) subunit ...Name: Guanine nucleotide-binding protein G(s) subunit alpha isoforms short, Guanine nucleotide-binding protein G(I)/G(S)/G(T) subunit beta-1, Guanine nucleotide-binding protein G(I)/G(S)/G(O) subunit gamma-2, Pituitary adenylate cyclase-activating polypeptide type I receptor
type: complex / ID: 2 / Parent: 1 / Macromolecule list: #1-#3, #6
Source (natural)Organism: Homo sapiens (human)

+
Supramolecule #3: Nanobody35

SupramoleculeName: Nanobody35 / type: complex / ID: 3 / Parent: 1 / Macromolecule list: #4
Source (natural)Organism: Lama glama (llama)

+
Supramolecule #4: Pituitary adenylate cyclase activating polypeptide-27

SupramoleculeName: Pituitary adenylate cyclase activating polypeptide-27 / type: complex / ID: 4 / Parent: 1 / Macromolecule list: #5
Source (natural)Organism: Homo sapiens (human)

+
Macromolecule #1: Guanine nucleotide-binding protein G(s) subunit alpha isoforms short

MacromoleculeName: Guanine nucleotide-binding protein G(s) subunit alpha isoforms short
type: protein_or_peptide / ID: 1 / Number of copies: 1 / Enantiomer: LEVO
Source (natural)Organism: Homo sapiens (human)
Molecular weightTheoretical: 45.683434 KDa
Recombinant expressionOrganism: Trichoplusia ni (cabbage looper)
SequenceString: MGCLGNSKTE DQRNEEKAQR EANKKIEKQL QKDKQVYRAT HRLLLLGAGE SGKNTIVKQM RILHVNGFNG EGGEEDPQAA RSNSDGEKA TKVQDIKNNL KEAIETIVAA MSNLVPPVEL ANPENQFRVD YILSVMNVPD FDFPPEFYEH AKALWEDEGV R ACYERSNE ...String:
MGCLGNSKTE DQRNEEKAQR EANKKIEKQL QKDKQVYRAT HRLLLLGAGE SGKNTIVKQM RILHVNGFNG EGGEEDPQAA RSNSDGEKA TKVQDIKNNL KEAIETIVAA MSNLVPPVEL ANPENQFRVD YILSVMNVPD FDFPPEFYEH AKALWEDEGV R ACYERSNE YQLIDCAQYF LDKIDVIKQA DYVPSDQDLL RCRVLTSGIF ETKFQVDKVN FHMFDVGAQR DERRKWIQCF ND VTAIIFV VASSSYNMVI REDNQTNRLQ AALKLFDSIW NNKWLRDTSV ILFLNKQDLL AEKVLAGKSK IEDYFPEFAR YTT PEDATP EPGEDPRVTR AKYFIRDEFL RISTASGDGR HYCYPHFTCA VDTENIRRVF NDCRDIIQRM HLRQYELL

UniProtKB: Guanine nucleotide-binding protein G(s) subunit alpha isoforms short

+
Macromolecule #2: Guanine nucleotide-binding protein G(I)/G(S)/G(T) subunit beta-1

MacromoleculeName: Guanine nucleotide-binding protein G(I)/G(S)/G(T) subunit beta-1
type: protein_or_peptide / ID: 2 / Number of copies: 1 / Enantiomer: LEVO
Source (natural)Organism: Homo sapiens (human)
Molecular weightTheoretical: 38.534062 KDa
Recombinant expressionOrganism: Trichoplusia ni (cabbage looper)
SequenceString: MHHHHHHGSS GSELDQLRQE AEQLKNQIRD ARKACADATL SQITNNIDPV GRIQMRTRRT LRGHLAKIYA MHWGTDSRLL VSASQDGKL IIWDSYTTNK VHAIPLRSSW VMTCAYAPSG NYVACGGLDN ICSIYNLKTR EGNVRVSREL AGHTGYLSCC R FLDDNQIV ...String:
MHHHHHHGSS GSELDQLRQE AEQLKNQIRD ARKACADATL SQITNNIDPV GRIQMRTRRT LRGHLAKIYA MHWGTDSRLL VSASQDGKL IIWDSYTTNK VHAIPLRSSW VMTCAYAPSG NYVACGGLDN ICSIYNLKTR EGNVRVSREL AGHTGYLSCC R FLDDNQIV TSSGDTTCAL WDIETGQQTT TFTGHTGDVM SLSLAPDTRL FVSGACDASA KLWDVREGMC RQTFTGHESD IN AICFFPN GNAFATGSDD ATCRLFDLRA DQELMTYSHD NIICGITSVS FSKSGRLLLA GYDDFNCNVW DALKADRAGV LAG HDNRVS CLGVTDDGMA VATGSWDSFL KIWN

UniProtKB: Guanine nucleotide-binding protein G(I)/G(S)/G(T) subunit beta-1

+
Macromolecule #3: Guanine nucleotide-binding protein G(I)/G(S)/G(O) subunit gamma-2

MacromoleculeName: Guanine nucleotide-binding protein G(I)/G(S)/G(O) subunit gamma-2
type: protein_or_peptide / ID: 3 / Number of copies: 1 / Enantiomer: LEVO
Source (natural)Organism: Homo sapiens (human)
Molecular weightTheoretical: 7.861143 KDa
Recombinant expressionOrganism: Trichoplusia ni (cabbage looper)
SequenceString:
MASNNTASIA QARKLVEQLK MEANIDRIKV SKAAADLMAY CEAHAKEDPL LTPVPASENP FREKKFFCAI L

UniProtKB: Guanine nucleotide-binding protein G(I)/G(S)/G(O) subunit gamma-2

+
Macromolecule #4: Nanobody35

MacromoleculeName: Nanobody35 / type: protein_or_peptide / ID: 4 / Number of copies: 1 / Enantiomer: LEVO
Source (natural)Organism: Lama glama (llama)
Molecular weightTheoretical: 15.140742 KDa
Recombinant expressionOrganism: Escherichia coli (E. coli)
SequenceString:
QVQLQESGGG LVQPGGSLRL SCAASGFTFS NYKMNWVRQA PGKGLEWVSD ISQSGASISY TGSVKGRFTI SRDNAKNTLY LQMNSLKPE DTAVYYCARC PAPFTRDCFD VTSTTYAYRG QGTQVTVSSH HHHHHEPEA

+
Macromolecule #5: Pituitary adenylate cyclase-activating polypeptide

MacromoleculeName: Pituitary adenylate cyclase-activating polypeptide / type: protein_or_peptide / ID: 5 / Number of copies: 1 / Enantiomer: LEVO
Source (natural)Organism: Homo sapiens (human)
Molecular weightTheoretical: 3.154642 KDa
SequenceString:
HSDGIFTDSY SRYRKQMAVK KYLAAVL

UniProtKB: Pituitary adenylate cyclase-activating polypeptide

+
Macromolecule #6: Pituitary adenylate cyclase-activating polypeptide type I receptor

MacromoleculeName: Pituitary adenylate cyclase-activating polypeptide type I receptor
type: protein_or_peptide / ID: 6 / Number of copies: 1 / Enantiomer: LEVO
Source (natural)Organism: Homo sapiens (human)
Molecular weightTheoretical: 55.439207 KDa
Recombinant expressionOrganism: Trichoplusia ni (cabbage looper)
SequenceString: DYKDDDDLEV LFQGPAMHSD CIFKKEQAMC LEKIQRANEL MGFNDSSPGC PGMWDNITCW KPAHVGEMVL VSCPELFRIF NPDQVWETE TIGESDFGDS NSLDLSDMGV VSRNCTEDGW SEPFPHYFDA CGFDEYESET GDQDYYYLSV KALYTVGYST S LVTLTTAM ...String:
DYKDDDDLEV LFQGPAMHSD CIFKKEQAMC LEKIQRANEL MGFNDSSPGC PGMWDNITCW KPAHVGEMVL VSCPELFRIF NPDQVWETE TIGESDFGDS NSLDLSDMGV VSRNCTEDGW SEPFPHYFDA CGFDEYESET GDQDYYYLSV KALYTVGYST S LVTLTTAM VILCRFRKLH CTRNFIHMNL FVSFMLRAIS VFIKDWILYA EQDSNHCFIS TVECKAVMVF FHYCVVSNYF WL FIEGLYL FTLLVETFFP ERRYFYWYTI IGWGTPTVCV TVWATLRLYF DDTGCWDMND STALWWVIKG PVVGSIMVNF VLF IGIIVI LVQKLQSPDM GGNESSIYLR LARSTLLLIP LFGIHYTVFA FSPENVSKRE RLVFELGLGS FQGFVVAVLY CFLN GEVQA EIKRKWRSWK VNRYFAVDFK HRHPSLASSG VNGGTQLSIL SKSSSQIRMS GLPADNLATP AGLEVLFQGP HHHHH HHH

UniProtKB: Pituitary adenylate cyclase-activating polypeptide type I receptor

+
Macromolecule #7: water

MacromoleculeName: water / type: ligand / ID: 7 / Number of copies: 11 / Formula: HOH
Molecular weightTheoretical: 18.015 Da
Chemical component information

ChemComp-HOH:
WATER

-
Experimental details

-
Structure determination

Methodcryo EM
Processingsingle particle reconstruction
Aggregation stateparticle

-
Sample preparation

Concentration5.15 mg/mL
BufferpH: 7.4
VitrificationCryogen name: ETHANE

-
Electron microscopy

MicroscopeFEI TITAN KRIOS
Image recordingFilm or detector model: GATAN K3 BIOQUANTUM (6k x 4k) / Detector mode: COUNTING / Average electron dose: 52.4 e/Å2
Electron beamAcceleration voltage: 300 kV / Electron source: FIELD EMISSION GUN
Electron opticsIllumination mode: FLOOD BEAM / Imaging mode: BRIGHT FIELD / Nominal defocus max: 1.4000000000000001 µm / Nominal defocus min: 0.5 µm
Experimental equipment
Model: Titan Krios / Image courtesy: FEI Company

+
Image processing

Startup modelType of model: OTHER
Final reconstructionResolution.type: BY AUTHOR / Resolution: 2.3 Å / Resolution method: FSC 0.143 CUT-OFF / Number images used: 440740
Initial angle assignmentType: MAXIMUM LIKELIHOOD
Final angle assignmentType: MAXIMUM LIKELIHOOD
FSC plot (resolution estimation)

+
About Yorodumi

-
News

-
Feb 9, 2022. New format data for meta-information of EMDB entries

New format data for meta-information of EMDB entries

  • Version 3 of the EMDB header file is now the official format.
  • The previous official version 1.9 will be removed from the archive.

Related info.:EMDB header

External links:wwPDB to switch to version 3 of the EMDB data model

-
Aug 12, 2020. Covid-19 info

Covid-19 info

URL: https://pdbjlvh1.pdbj.org/emnavi/covid19.php

New page: Covid-19 featured information page in EM Navigator.

Related info.:Covid-19 info / Mar 5, 2020. Novel coronavirus structure data

+
Mar 5, 2020. Novel coronavirus structure data

Novel coronavirus structure data

Related info.:Yorodumi Speices / Aug 12, 2020. Covid-19 info

External links:COVID-19 featured content - PDBj / Molecule of the Month (242)：Coronavirus Proteases

+
Jan 31, 2019. EMDB accession codes are about to change! (news from PDBe EMDB page)

EMDB accession codes are about to change! (news from PDBe EMDB page)

  • The allocation of 4 digits for EMDB accession codes will soon come to an end. Whilst these codes will remain in use, new EMDB accession codes will include an additional digit and will expand incrementally as the available range of codes is exhausted. The current 4-digit format prefixed with “EMD-” (i.e. EMD-XXXX) will advance to a 5-digit format (i.e. EMD-XXXXX), and so on. It is currently estimated that the 4-digit codes will be depleted around Spring 2019, at which point the 5-digit format will come into force.
  • The EM Navigator/Yorodumi systems omit the EMD- prefix.

Related info.:Q: What is EMD? / ID/Accession-code notation in Yorodumi/EM Navigator

External links:EMDB Accession Codes are Changing Soon! / Contact to PDBj

+
Jul 12, 2017. Major update of PDB

Major update of PDB

  • wwPDB released updated PDB data conforming to the new PDBx/mmCIF dictionary.
  • This is a major update changing the version number from 4 to 5, and with Remediation, in which all the entries are updated.
  • In this update, many items about electron microscopy experimental information are reorganized (e.g. em_software).
  • Now, EM Navigator and Yorodumi are based on the updated data.

External links:wwPDB Remediation / Enriched Model Files Conforming to OneDep Data Standards Now Available in the PDB FTP Archive

-
Yorodumi

Thousand views of thousand structures

  • Yorodumi is a browser for structure data from EMDB, PDB, SASBDB, etc.
  • This page is also the successor to EM Navigator detail page, and also detail information page/front-end page for Omokage search.
  • The word "yorodu" (or yorozu) is an old Japanese word meaning "ten thousand". "mi" (miru) is to see.

Related info.:EMDB / PDB / SASBDB / Comparison of 3 databanks / Yorodumi Search / Aug 31, 2016. New EM Navigator & Yorodumi / Yorodumi Papers / Jmol/JSmol / Function and homology information / Changes in new EM Navigator and Yorodumi

Read more
